V2.8 · hatch on the front face
Superseded when V2.8B moved the hatch to +X.
Set aside.CodeCLX-CT-01
TitleCreator-tech carry system · V2 Tapered Pro
DisciplineIndustrial design · research-led product architecture
DateFiles Jun 2026
StatusDesigned · CAD blockout, V2.1 refinement pending
Highest claim: designed, as a CAD blockout under review. Physical evidence: none.
[ LAB · AS DESIGNED ][ INVESTIGATION · AS EVIDENCED ] [+]
Not a camera backpack.
A spine-centred creator workstation — designed from review evidence outward, not from a silhouette inward. What exists is a CAD blockout under review: evidence 40% verified, 60% source-pending.
Origin
1
2
3
4
1480 × 285 × 180→150 mm tapered envelopeDesigned · blockout
2Side hatch 230 × 120 mm on +XDesigned · blockout start dimension
3M04 laptop tunnel · M05 cassette — cued, not validatedConcept · cued
4Spine channel 36 mm on the flat back datum — origin at its baseDesigned · blockout
5Evidence · 8 of 20 review rows source-verified12 rows source-pending · 4 products
- 1480 × 285 × 180→150 mm tapered envelopeDesigned · blockout
- 2Side hatch 230 × 120 mm on +XDesigned · blockout start dimension
- 3M04 laptop tunnel · M05 cassette — cued, not validatedConcept · cued
- 4Spine channel 36 mm on the flat back datum — origin at its baseDesigned · blockout
- 5Evidence · 8 of 20 review rows source-verified12 rows source-pending · 4 products
150 · shoulder180 · lower bodyZ 480Z 0 · originHatch · +X facePlan key−X dock+X hatch
1
2
3
4
1Flat back datum · origin at its base · +Z up, +Y front, +X hatch sideDesigned · axis doctrine
2M04 laptop tunnel · M05 cassette — cued, not proven as sealed volumesConcept · cued
3M02 camera core 290 × 190 × 130 mm · start dimension, not a specificationDesigned · blockout
4Retention gate · a placeholder for position and swing — mechanism not modelledConcept · placeholder
5Evidence · 8 of 20 review rows source-verified12 rows source-pending · not engineering validation
- 1Flat back datum · origin at its base · +Z up, +Y front, +X hatch sideDesigned · axis doctrine
- 2M04 laptop tunnel · M05 cassette — cued, not proven as sealed volumesConcept · cued
- 3M02 camera core 290 × 190 × 130 mm · start dimension, not a specificationDesigned · blockout
- 4Retention gate · a placeholder for position and swing — mechanism not modelledConcept · placeholder
- 5Evidence · 8 of 20 review rows source-verified12 rows source-pending · not engineering validation
No product imagery exists. No physical prototype. The blockout is not an engineering check.
- [ On this sheet ]
- 02Question2 min
- 03Mechanism3 min
- 04Inside5 min
- 05Pigment2 min
- 06Decisions1 min
- 07Ledger3 min
- 08Provenance2 min
- 09Next specimen1 min
- Code
- CLX-CT-01
- Discipline
- Industrial design — review mining → requirements → modules → CAD blockout
- Date
- Files dated 13–14 Jun 2026 · project year to confirm
- Status
- CAD blockout V2.x under review · V2.1 refinement pending
- Physical evidence
- None — CAD blockout only
- Image
- Schematic drawings from the blockout spec — no render
- Sheet
- 08 / 11
- Evidence
- 8 of 20 review rows source-verified · 4 products
02 · Question
Designed from review evidence outward, not from a silhouette inward.
The category default is a soft, top-loading camera bag that treats the laptop, audio kit and cables as afterthoughts stuffed around the camera core. CLX-CT-01 inverts that: the load is organised around the spine first, with protected rapid access and independent compartments designed as primary structure rather than as pockets. The chain is traceable — review mining, complaint clusters, requirements, eight modules, form, CAD blockout — and the evidence is reported plainly.
Products surveyed (4): Peak Design Everyday V2 · WANDRD PRVKE 21L · Shimoda Action X25 · Nomatic McKinnon. No review quotes or scores are reproduced here.
Doctrine · six frozen pillars
Provisional in detail — corrections may refine a pillar's spec, not remove the pillar.
- Pillar 01Protected rapid-access side hatchFrozen · exterior
- Pillar 02Anti-spill retentionFrozen · exterior
- Pillar 03Semi-rigid frameFrozen · exterior
- Pillar 04Spine-centred placementFrozen · exterior
- Pillar 05Independent laptop tunnelInternal · not on exterior · cued
- Pillar 06Removable cable / audio cassetteInternal · not on exterior · cued
03 · Mechanism
Build the blockout in ten steps.
Datums first, then volumes back to front, then cuts and placeholders last. Step through the modelling plan; the taper is drawn live, and the side hatch swings while the amber gate stays.
Side · from +X
150 · top180 · base480
Axonometric · back right
Origin
Plan · section at Z 195 · reduced
Back · datum−X · dock+X · hatch
S10 · 4 harness mount points · rear face · placeholders
- 01Set flat back datum planeThe master reference: a vertical plane, 480 mm tall × 285 mm wide — the frame-sheet face and harness mount surface. It never curves.Depends · World origin
- 02Build outer tapered envelopeExtrude the body forward from the back plane with the V2 taper, 180 → 150 mm. The back edge stays flat and vertical; the taper happens on the front face only.Depends · Step 1 plane
- 03Add laptop tunnel slab inboard of the coreA thin vertical slab immediately in front of the back plane: 28 mm deep, 390–420 mm usable inside the 480 mm body. The core never touches the back directly.Depends · Back plane, step 1
- 04Add camera core volumeThe dominant volume, 290 H × 190 W × 130 D, biased toward the spine with its back face against the tunnel. The heaviest mass.Depends · Tunnel front face, step 3
- 05Cut side hatch openingCut the 230 × 120 mm hatch bounding box on the +X side — the protected rapid-access opening, placed so it never conflicts with the dock.Depends · Core, step 4
- 06Add retention gate placeholderA thin curved panel at the mouth of the hatch. Blockout only — it represents position and swing, not mechanism, and holds remaining gear during partial opening.Depends · Hatch cut, step 5
- 07Add cassette volumeThe removable cable / audio cassette, 200 × 120 × 40 mm, in the front-mid zone below the hatch reach. It must lift out without intruding on the core access path.Depends · Core front face, step 4
- 08Add tripod dock channelA 40 mm vertical channel on the −X exterior, with a lower anchor cup and an upper strap position — clear of the hatch on the other side. That separation is the point.Depends · Envelope, step 2
- 09Add spine channel and back padsThe central 36 mm recessed spine channel, flanked by symmetric ventilation pads. Crisp edges — the architectural signature line, not soft padding.Depends · Back plane, step 1
- 10Add placeholder harness mount pointsFour mount points on the rear of the back plane, two upper and two lower. The harness itself is not modelled — only its attachment datum.Depends · Back plane, step 1
Sizes are the blockout's starting point, not its specification. Positions are schematic; the hatch hinge side is not specified, so its swing is drawn for illustration only. Designed · modelling plan, not final
Tool mapping · units mm
- Rhino
- NURBS · CPlane datums, Box / ExtrudeCrv, BooleanDifference
- Fusion 360
- Parametric · construction planes, sketch + extrude, combine / cut
- Blender
- Mesh · empties as datums, cube primitives, boolean modifier
04 · Inside
Each stage is accountable to the one before it.
VisibleHidden / cuedDatum · verifiedPending · gateFrozen pillar · tunnel · dock
A → F · evidence-to-design chain
- ACompetitive review mining4 products · 8 verified rows · complaint extraction
- BComplaint cluster scoringWeighted model · opportunity ranking
- CRequirement definitionR-series frozen requirements · T01–T05 provisional targets
- DSystem & component architecture8 modules · M01–M08
- EForm strategy & silhouetteTaper rationale · view logic
- FCAD blockout & modelling planBlender blockout · V2.x refinement pending
Complaint clusterSystem answerRequirement IDsModules
Complaint clusterWeight + fatigueBags become uncomfortable as bodies, lenses, laptop, batteries and accessories accumulate.
System answerSpine-centred load zoneHeavy core mass kept close to the back datum; a semi-rigid frame holds the geometry.
Requirement IDsT01R01R02
ModulesM01M02
Complaint clusterSlow / tight accessSide access gets snug, awkward or blocked once a real creator kit is loaded.
System answerProtected rapid-access hatchA deliberate side hatch reaches the body + attached lens without a full opening.
Requirement IDsR04R16T02
ModulesM03
Complaint clusterProtection / access trade-offProtected systems slow the user down; rapid-access systems risk spill, conflict or disorder.
System answerRetention gate + separated pathsAnti-spill gate, independent laptop tunnel, removable cassette, tripod dock opposite the hatch.
Requirement IDsR05R11T04
ModulesM03M04M05M06
R = frozen requirement Specified intent · T = provisional target, carries a “pending” flag Pending — the T01–T05 namespace was introduced to resolve a duplicate-ID conflict (R12–R16), a fix to traceability, not cosmetics. R16 is quoted from the earlier June triplet; R12–R16 were later re-namespaced, so its current ID is unconfirmed. The Modules column is this sheet’s reading of each system answer, not a mapping stated in the source.
Eight modules · numbering locked to the component architecture
- M01Back panel + frame sheetLoad-bearing spine datum, semi-rigid frame sheet, central spine channel, rear pad and harness-mount surface.Datum / frame
- M02Camera core / divider cassetteSpine-close protected camera volume for body, primary lens and modular dividers.Core payload
- M03Side hatch + retention gateProtected +X side access with an anti-spill, partial-opening gate.Access path
- M04Laptop tunnelIndependent 14–16 inch laptop path between the back plane and the camera core.Internal · cued
- M05Cable / audio cassetteRemovable front-mid organiser for lavs, SD cards, batteries and cables.Internal · cued
- M06Tripod dockExterior −X dock channel, separated from the hatch side to avoid access conflict.Exterior channel
- M07Harness / load transferRear-mounted shoulder / hip load interface — only mount points exist in the current blockout.Future detail
- M08Outer shell / weather layerQuiet tapered shell, weather layer, front restraint and low-signal exterior surface.Envelope
The blockout establishes M01 / M02 / M03 / M06 / M08; M04 and M05 stay internal and cued until section cuts or exploded views prove them.
Axis doctrine
| Axis | Direction | Carries |
|---|---|---|
| +Z | Up | Blender-native vertical axis |
| +Y | Front / depth | Toward the front shell and cassette zone |
| +X | Hatch side | Protected rapid-access side hatch |
| −X | Tripod side | Tripod dock channel, opposite the hatch |
| Origin | Base of the flat back plane | Centred left–right; every module coordinate references this datum |
Follows the later Blender axis correction. The Phase 08 modelling plan had used +Y up and +Z toward the front.
Form spec · start dimensions
| Element | Spec, mm | Role |
|---|---|---|
| Envelope | 480 × 285 × 180→150 | Frozen carry volume |
| Depth taper | 180 → 150 | Centre of gravity + worn read |
| Camera core | 290 × 190 × 130 | Protected payload |
| Side hatch | 230 × 120 | Rapid access, +X face |
| Spine channel | 36 | Load centring, back plane |
| Laptop tunnel | 28 deep · 390–420 H | Independent sleeve (internal) |
| Cassette | 200 × 120 × 40 | Removable organiser (internal) |
| Tripod dock | 40 channel | Exterior, −X |
The taper runs from 180 mm at the lower / mid body to 150 mm at the shoulder, pulling mass toward the wearer's centre of gravity; corners soften at R22. The modelling plan words the taper back-to-front; these drawings follow the case page.
Blockout version log
- V2.8First assembled lock · undersized envelope, no taper, hatch on the front faceSuperseded
- V2.8BSpec-locked envelope + true taper · hatch moved to +X · all pillars cuedSuperseded
- V2.xCorrected upright blockout · taper reads in render · matches the baseline envelope in scriptCurrent review state
- V2.1Next refinement pass — flush hatch, recessed dock, softer backpack massing, clean off-object labelsPending
Version glyphs are illustrative side profiles, not renders.
V2.x review · matches spec in script
- Envelope 480 × 285 × 180→150 built as a true tapered mesh
- Depth taper present in geometry; reads in the side render
- Hatch on +X · recess dimensioned 230 × 120
- Spine channel 36 mm in script
- Upright, Z-up, single assembled mass
- Tripod dock, bands, contact pads, handle attached
V2.x review · flagged / open
- Front cues dropped → clean service mark only (intentional; now documented)
- M05 / M06 cued as surface relief, not validated as sealed volumes
- Hero render at 64 mm exaggerates verticality — switch to 35–40 mm
- Flat accessory boxes meet angled taper faces — check top-edge fit
- Proportions still read tall / narrow vs spec — needs the V2.1 pass
Read from the generating script and cross-checked against viewport renders: a visual / code review of a blockout, not engineering validation.
05 · Pigment & material
Colour is module code, not a colourway.
Five authored colours carry meaning in the June 2026 drawings and badges. There is no CMF yet: the V2.1 pass asks for “subtle module colours”, with no final fabric or straps.
Frozen pillars · tunnel · dock
Authored · case-page badges + June diagrams
Camera core
Authored · stroke on #3A1C12 in the June diagrams
Verified · flat back datum
Authored · evidence meter + datum line
Pending · retention gate
Authored · evidence meter + gate
Cued · M04 / M05
Authored · case-page badges
Material
Not specified. The blockout is solids only — no fabric thickness, surfacing, straps or harness geometry. Finish data (roughness, gloss, L*) does not exist for this project.
Not claimed · CMF, fabric, weather performance
Form rules
- FR-01The spine line is the signatureThe back-panel channel expresses the load path and the structural datum.Do · clean central spine channelDon’t ·
Busy padding or branding - FR-02Access reads as one gestureThe side hatch must be obvious, flush and one-handed.Do · single deliberate hatch seamDon’t ·
Competing zippers - FR-03Quiet front, no gear signalA flat professional front shell avoids tactical theft cues.Do · matte, calm, low-signalDon’t ·
MOLLE, daisy chains, logos - FR-04Dock stows invisibleThe tripod channel integrates into the side seam and never crosses the hatch path.Do · recessed side channelDon’t ·
Pipe-like external tube
Form rules are design intent Designed · rules, not yet built
06 · Decisions
What was set aside, and why.
D1Hatch placement
V2.8B onward · hatch on +X
With the tripod dock on −X, the hatch and the dock never share a side.
D2Envelope
V2.8 · undersized, no taper
The first assembled lock.
Set aside.V2.8B · spec-locked envelope, true taper
480 × 285 × 180 → 150 mm; the V2.x review reads it as a true tapered mesh.
D3Hero lens
64 mm · exaggerates verticality
The 285 mm width reads narrower than it is.
Set aside.35–40 mm · lower camera height
The stated rule for any hero render of the blockout.
D4Labels
Labels printed onto the model
Flagged “remove” in the first blockout review.
Set aside.Annotations off-object, in the layout
Leaders and captions live on the sheet, not the shell.
D5Evidence scoring
Hand-assigned complaint scores
Fake precision.
Set aside.A weighted model
Overclaiming headlines softened; targets carry a pending flag.
Glyphs are illustrative diagrams of each decision, not renders.
07 · Claim ledger
What is claimed, at what level.
| Claim | Value | Level | Qualifier |
|---|---|---|---|
| Tapered envelope | 480 × 285 × 180→150 mm | Designed · blockout | Built as a true tapered mesh; matches the spec in script (V2.x review). |
| Depth taper | 180 → 150 mm | Designed | Lower / mid body to shoulder; pulls mass toward the wearer's centre of gravity. |
| Corner softening | R22 mm | Designed | An earlier draft listed R18–24 shell · R8–12 hatch · R6–10 spine. |
| Camera core · M02 | 290 × 190 × 130 mm | Designed · start dimension | Spine-biased; back face against the laptop tunnel. |
| Side hatch · M03 | 230 × 120 mm on +X | Designed · start dimension | An earlier draft marked the size “source pending”. |
| Retention gate · M03 | Placeholder | Concept · placeholder | Position and swing only, not its mechanism. |
| Spine channel · M01 | 36 mm | Designed · blockout | In script. |
| Tripod dock · M06 | 40 mm channel, −X | Designed · start dimension | On the side opposite the hatch. |
| Laptop tunnel · M04 | 28 deep · 390–420 usable H · 14–16 in | Concept · cued | Internal; not proven as a sealed independent volume. |
| Cable / audio cassette · M05 | 200 × 120 × 40 mm | Concept · cued | Internal; not proven as a sealed independent volume. |
| Harness · M07 | 4 mount points | Concept · placeholder | The harness itself is not modelled. |
| Review evidence | 8 of 20 rows source-verified · 40% | EV-V01–EV-V08, across four products. | |
| Remaining rows | 12 of 20 · 60% | Source-pending | Treated as benchmark, labelled wherever they appear. |
| Convergent finding | Weight vs protection / access | From the verified rows; converged across all four products. | |
| Must-have requirements | R01 R02 R04 R05 R06 R08 R10 R11 | Specified intent | Frozen R-series requirements. |
| Provisional targets | T01–T05 | Specified intent · pending flag | T02 is a retrieval target “to be validated physically”. |
| Six pillars | Frozen in intent | Designed · doctrine | Provisional in detail. |
| Blockout review | V2.x matches the baseline envelope | Designed · visual / code review | Not engineering validation; V2.1 pending. |
Not claimed
- Engineering validation — a blockout is not an engineering check
- Sign-off of any kind
- M04 / M05 as sealed independent volumes
- A physical prototype, carried loads or load ratings
- Fabric, straps, weather performance or CMF
- Review quotes or scores attached to named products
- The earlier research-phase counts as current
- A product render — none exists
Open items
- V2.1 refinement pass — flush hatch, recessed dock, softer backpack massing, clean off-object labels TBC
- Hero render lens: 64 mm exaggerates verticality — re-shoot at 35–40 mm TBC
- Flat accessory boxes meet the angled taper faces — check top-edge fit TBC
- Proportions still read tall / narrow against the spec TBC
- 12 of 20 review rows source-pending TBC
- Validate the core volume against a real hybrid kit, and the hatch against body + lens clearance, before refining anything TBC
- T02 retrieval target — to be validated physically TBC
08 · Provenance, credits, revisions
Where every image comes from.
- §01 LAB · axonometric of the tapered envelope with module volumes · schematic from blockout spec — not a render · drawn for this sheetSchematic
- §01 INVESTIGATION · side section · redrawn to the blockout start dimensions — not a render, not measured from the modelSchematic
- §03 · side, axonometric and plan section · schematic from the CAD modelling plan, Phase 08Schematic
- §04 · June 2026 diagrams 1–3 · re-inked with this site's inks; geometry and labels unchanged · not to scaleDiagram
- Product imagery · none exists; any render would be new work, labelled as a blockout and shot at 35–40 mmNone
- Evidence · review mining across four products · no quotes or scores reproducedResearch
- Tools · Blender blockout from a generating script · modelling plan written for Rhino, Fusion 360 or Blender · millimetresTools
- Credits · Bahareh Arianejad · MALINYX Studio — industrial designCredit
| Rev | Date | Change |
|---|---|---|
| A | 13 Jun 2026 | Research phase · evidence collection (its counts were later superseded) |
| B | 14 Jun 2026 | CAD modelling plan · ten-step blockout sequence (Phase 08) |
| C | 14 Jun 2026 | Case page · 4 products, 8 verified rows · V2.x blockout review |
| — | Undated | Blockout V2.8 → V2.8B → V2.x |
| D | Pending | V2.1 refinement pass |
| E | 2 Oct 2026 | This sheet · June diagrams re-inked; axonometric and section drawn from the blockout spec |
Dates A–C are the dates of the source files; the blockout versions carry no dates.
09 · Next specimen
Specimen 07 / 08 · sheet 09
ÉCLOS — refillable lipstick
The case you keep. The cartridge you replace.
Concept visualisation · AI-generated
Open sheet 09
