MALINYX

Industrial · Creator-tech carry system

CLX‑CT‑01

A spine-centred carry system for creators, designed from review evidence outward: complaints traced to requirements, requirements to eight modules, modules to a tapered CAD blockout.

Role
Research, requirements, CAD blockout
Project type
Independent project
Stage
Design study
Year
2026
Tools
Rhino (CAD blockout)
Images
Technical diagrams
Axonometric of the CLX-CT-01 CAD blockout, seen from behind and from the hatch side: a tapered envelope 480 mm tall, 285 mm wide and 180 mm deep at the base, 150 mm at the top, with coded volumes for the back datum and back panel, camera core, side hatch and retention gate, laptop tunnel and cassette (placeholder volumes), tripod dock, harness mount points and outer shell; blockout start dimensions, positions schematic.
01 — The product in 10 secondsCLX-CT-01

Not a camera backpack.

What it is
A 480 × 285 mm tapered carry system for creators, built around a camera core, a side hatch, a laptop tunnel and a tripod dock.
Who it is for
Creators who carry a camera, a laptop, audio kit and a tripod, and need fast access.
The problem
Camera bags trade protection against access: protected ones are slow to open, quick-access ones spill.
What is different
The load sits against the spine, and every module traces back to a requirement drawn from customer reviews — 8 of 20 review findings traced to their source so far.
Tapered envelope · 285 wide · 180→150 deepDesigned
480 mm
Review findings traced to their source (8 of 20)Counted · review findings
40 %
Side hatch 230 × 120 mmDesigned
230 mm
Modules, each traced to its requirementsDesigned
8
02 — The design challenge

Designed from review evidence outward, not from a silhouette inward.

The category default is a soft, top-loading camera bag that treats the laptop, audio kit and cables as afterthoughts around the camera core. One trade-off converged across all four products surveyed — weight against protection and access — and it is the only finding strong enough to act on.

Plan section at Z 195 mm: where each access path sits
Plan section at Z 195 mm: where each access path sits
03 — My contributionIndependent project

What I did.

  • Competitive review mining (4 products)
  • Requirements and traceability
  • System architecture: 8 modules
  • Form strategy
  • CAD blockout and modelling plan
  • Diagrams
04 — Design response3 decisions · reason · evidence

The decisions that shaped it.

Decision 01

A spine-centred load zone

The heavy camera core sits against a 28 mm laptop tunnel on the flat back datum; a semi-rigid frame holds the geometry.

Designed · blockout
Side section with blockout start dimensions
Side section with blockout start dimensions

Decision 02

One protected side hatch

A 230 × 120 mm hatch on one side reaches the body and an attached lens without a full opening; an anti-spill gate holds the rest.

Designed · blockout start dimension

Decision 03

Paths that never cross

An independent laptop tunnel, a removable cassette and a tripod dock on the side opposite the hatch, so access paths stay separate.

Specified intent · placeholder volumes
05 — Product architecture & engineeringDesign study

How it is built.

A CAD blockout and a ten-step modelling plan, not an engineering check. Sizes are the blockout’s starting point, not its specification; positions are schematic.

Key dimensions and their claim level
ItemValueLevel
Envelope480 × 285 × 180→150 mmDesigned · blockout
Camera core290 × 190 × 130 mmDesigned · blockout
Side hatch230 × 120 mm, hatch sideDesigned · blockout
Laptop tunnel28 mm deep · 390–420 mm usableSpecified intent · placeholder volume
Cassette200 × 120 × 40 mmSpecified intent · placeholder volume
Tripod dock40 mm channel, opposite the hatchDesigned · blockout
Spine channel36 mmDesigned · blockout

8 modules

M01
Back panel + frame sheetLoad-bearing spine datum, frame sheet, spine channel, harness-mount surface
M02
Camera coreSpine-close protected volume for the body, primary lens and dividers
M03
Side hatch + retention gateProtected side access with an anti-spill gate
M04
Laptop tunnelIndependent 14–16 inch laptop path between back and core · placeholder volume
M05
Cable / audio cassetteRemovable front-mid organiser · placeholder volume
M06
Tripod dockExterior channel, opposite the hatch
M07
Harness / load transferOnly the four mount points exist so far
M08
Outer shell / weather layerQuiet tapered shell, low-signal exterior
Engineering notes the longer story

The object is the load path. A flat back datum, a laptop tunnel, a camera core behind a side hatch, a retention gate and a tripod dock — each module carries the requirement IDs that justify it.

8 of 20 customer-review findings are source-verified and 12 are pending; the laptop tunnel and cassette are placeholder volumes, not yet resolved.

06 — Project status

Design study
Stage
Design studyOne question taken deep — a mechanism, an interface, a form or a colour system — in CAD or drawings. Not a complete product.
What exists
Review evidence (8 of 20 findings verified), requirements, an 8-module architecture and a CAD blockout under review.
Physical evidence
None.
Not claimed
  • Product renders — none exist yet
  • CMF, fabric or weather performance
  • Load or comfort performance
Still open
  • Next refinement: flush hatch, recessed dock, softer massing.
  • Laptop tunnel and cassette are placeholder volumes, not yet proven as sealed volumes.
  • 12 of 20 review findings still source-pending.
Images
Schematics from the blockout spec — not renders.
